KFA2 GeForce GTX 1650 EX PLUS 4GB + PSU 850W
KFA2 GeForce GTX 1650 EX PLUS 1-Click OC 4GB
KFA2 GeForce GTX 1650 EX PLUS (1-Click OC), 4GB GDDR6 128-bit DP / HDMI / DVI-D, 128-bit, connections 1x DVI, 1x HDMI 2.0b, 1x DisplayPort 1.4a, chip TU116-300-A1 "Turing", chip clock 1410MHz, Boost: 1635MHz (OC Mode), memory 4GB GDDR6, 12000MHz, 128bit, 192GB / s, shader units / TMUs / ROPs 1280/88/48, cooling 2x axial fans (90mm ), Special features H.265 encode / decode, NVIDIA G-Sync, NVIDIA VR-Ready, backplate, HDCP 2.2, boost clock overclocked, interface PCIe 3.0 x16, DirectX 12.1, OpenGL 4.6, OpenCL 2.0, Vulkan 1.1.103, Shader model 6.3.
The graphics card is a heavily upgraded version of the Geforce GTX 1650. The new model calculates about twice as fast as the older Geforce GTX 1050 and is roughly 50 percent faster than the previous Geforce GTX 1650.
The Geforce GTX 1650 Plus slides between the Geforce GTX 1650 and the Geforce GTX 1660, but is technically much closer to the big model. The TU117 chip used in the Geforce GTX 1650 has 1,024 shader units, of which Nvidia only uses 896, and a 128-bit interface with 4 GBit / s fast GDDR5 memory. The Geforce GTX 1660, on the other hand, uses the larger TU116 with 1,402 ALUs from 1,536 possible shaders, plus a 192-bit interface.
For the Geforce GTX 1650 Plus, Nvidia relies on this TU116 and unlocks 1,280 calculators of the existing cores. The memory bus remains 128 bits wide, but is combined with 6 GBit / s GDDR6. The Super variant has 43 percent more computing speed and a 50 percent higher data transfer rate, which leads to a significant increase in performance.
Benchmarks in 1,920 × 1,080
The GeForce GTX 1650 Plus gains significantly with the cropped TU116 instead of the fully active TU117 GPU. The new graphics card is 36 percent faster on average than the GeForce GTX 1650, which is a good jump. This brings the graphics card fairly close to the GeForce GTX 1660, which only remains 11 percent faster.
The comparison to the GeForce GTX 1060 is interesting because it has the same number of shader units and an identical memory bandwidth as the GeForce GTX 1650 Plus. This means that only the clock and - even more important - the performance differences per ALU between Pascal and Turing make the difference. In the adapted test course, the new graphics card works six percent faster than the old middle class. It's not quite enough for the Radeon RX 590, although the difference is only marginal percentage points.
In contrast, the GeForce GTX 1650 Plus has to give up a bit in the frame times. In our test, the super model is only one percent ahead of the GeForce GTX 1060, so the Radeon RX 580 suddenly cuts off at the same speed and the Radeon RX 590 is ten percent better.
With the GeForce GTX 1650 Plus, Nvidia's entry-level Turing significantly increases in performance as long as there is enough memory. The super version comes pretty close to the GeForce GTX 1660 and can usually handle Full HD well, even if the details need to be reduced occasionally. The graphics card is faster than a GeForce GTX 1060 on the go. But there is a disadvantage: The 4 GB of memory is too scarce in this class these days, so the most beautiful textures cannot always be called up.
FSP Fortron/Source Hydro K PRO 850W
Up-to-date Circuit Design
A dual forward topology integrated with active PFC and PWM technology and double EMI filter delivers full power and enhance stability to your system.
Low Noise, Less Heat
Hydro K PRO series is equipped with the 120mm hydraulic bearing fan (HYB) which makes optimum cooling and reduces noise. Moreover, the lifespan of fan is longer than standard one.
Features
- Intel latest CPU ready
- Global safety approved
- Active PFC ≥ 0.9
- High efficiency ≧ 88%
- Powerful +12V single rail design
- Hold up time ≥ 17ms @ 80% load
- Double layer EMI filter
- 120mm hydraulic bearing (HYB) fan
- +5V & 3.3V DC to DC module design
- All black cables
- Complete protections: OCP/OVP/OPP/SCP
